The UNO 30 connector set consists of a round stainless steel holder with a V-shaped groove and an SK screw with a collar. Easy and quick installation is guaranteed, the SK screw head is inserted into the V-shaped groove of the tank when mounting. Optionally, a spring steel lock can be added, which locks the connection. Due to the round shape of the holder, it is easily mounted into a 30 mm / 7 mm drilled hole. Since the SK screw is attached to the component, the collar is designed to be perfectly set at the right height and easily fit into the holder, but at the same time it provides the ability to adjust it to compensate for any dimensional differences. UNO 30 can be used with 5-6 mm screws.
Advantages:
- Simple and fast - lock in place;
- Hidden - the connection is not visible;
- Self-tightening - based on the dovetail principle;
- Fast - can also be used with standard screws;
- Safe - the connection can be locked with a lock;
- Universal - used for various purposes;
- Strong - withstands up to 150 kg/1.5 kN.
Tip: UNO 30 is most often used for wooden components. However, it can also be used with standard dowels, thus opening up possibilities for attaching components to bricks, stones, concrete, dry walls, etc.
